HITBOT ECG-10 | Eletric gripper
The Hitbot Z-ECG-10 is a self-centering 3-finger electric gripper designed for high-precision industrial automation applications, especially for handling cylindrical parts and delicate components. Its automatic centering system provides greater stability and accuracy during gripping operations.
The gripper features a recommended payload capacity of up to 0.2 kg, a lightweight 0.5 kg body and a maximum adjustable stroke of 10 mm. Its gripping force is adjustable from 3 to 10 N, allowing safe handling of small and sensitive parts.
With ±0.03 mm repeatability and a linear guide motion system combined with a precision planetary reducer, the Z-ECG-10 delivers excellent performance in applications that require consistent positioning and continuous operation.
The model includes an integrated controller, Modbus RTU (RS-485) and I/O communication, as well as intelligent functions such as object drop detection and precise force, position and speed control. Its compact structure allows easy integration with robotic arms, cobots and automated systems.
Highlights
Three-Finger Centering Design
Secure and stable gripping
The three-finger centering mechanism provides superior stability when handling cylindrical and irregularly shaped objects, ensuring consistent positioning and reliable grasping.
High-precision object handling
±0.03 mm Repeatability
With a repeatability of ±0.03 mm, the ECG-10 delivers accurate and repeatable positioning for assembly, inspection, laboratory, and electronics applications.
Ready for quick installation
Includes 2 m Connection Cables
Supplied with 2-meter power and communication cables, the ECG-10 simplifies installation, reduces commissioning time, and allows faster integration into robotic and automation systems.
Low cost solutions built with RBTX
